TFM-28
Features & Applications
Features
- Easy installation
- High reliability
- Supports high voltage
- Low power consumption
- High sound pressure levels
Applications
- Consumer Electronics
- Industrial & Automation
- Medical
- Security Access
- IoT & Smart Home
- Intercom
| Diameter | 30.6 mm |
|---|---|
| Height | 16 mm |
| SPL | 95 dB |
| Frequency | 3.4±0.5 kHz |
| Rated Voltage | 9VDC |
| Mounting | PIN |
Electrical Specifications
尺寸(毫米)
声压
Detailed Specifications
95dB/9VDC/30cm;85dB/9VDC/300cm,9VDC,6~14VDC,30mA/9VDC,3.4±0.5 KHz,-20~+70ºC,PC/Black,6g,More than 10N
